Inline Fans - Polypropylene (PP)

 5,990
  • Brand :Airegard
  • Type :AXA - 170
  • I/P Supply :220-240V, 50 Hz, Single Phase
  • Power (W) :40
  • Airflow (CMH) : 277
  • Airflow (CFM) : 164
  • Static-PR (mm-wc) : 15
  • Availability : In Stock

Other details


Technical Specification


Type I/P Supply AMPS(A) Power (W) RPM Airflow (CMH) Airflow (CFM) Static - PR(mm-wc) dBA CAP. μf ADMISSIBLE AMBIENT TEMP Weight (KG)
AXA - 170 220-240V, 50 Hz, Single Phase 0.17 40 2390 277 164 15 30 --- 55 4

Product Description


We offer the best quality AXA 170 inline fans with Polypropylene (PP) Body. Our offered AXA 170 inline fans are positioned inline with the ducting, bringing air from inside and outside of the establishment. Another name for an inline fan is a Mixed Flow fan. They are highly durable, reliable, and made with a Polypropylene body. Applications for inline fans include the ventilation of moist areas like restrooms, kitchens, laundry rooms, and many other commercial establishments.

  1. There are many different airflow capacities for inline fans available, making them suited for both commercial and residential uses. Various sizes, flow rates, ducting configurations, controls, and accessories are available at Kunjmart.

This Product has 3 years Warranty and This Product has a Power Supply of Single Phase with a frequency of 50 Hz with a Power consumption of 40 watts and 2390 RPM. This blower is known as the AXA 170 Inline Fans with Polypropylene (PP) Body and also Mix Flow Fan.

  • Max. airflow: 277 m3/h
  • Max. air pressure: 148 Pa
  • Noise Level: 30 dB(A) at high speed @3m
  • Ambient Temperature: -20 QC~ 60 QC
  • Net weight: 4 kgs

Purchase the Best quality AXA 170 Inline Fan Polypropylene (PP) Body only at Kunjmart As we are one of the reputed inline fans supplier and exporter in India. Customers can get the best products at affordable prices here. Moreover, our executives are always available to provide the best support for your queries. Contact us for the best offers.

Product Description


Type AXA - 170
I/P Supply 220-240V, 50 Hz, Single Phase
AMPS(A) 0.17
WATTS(W) 40
RPM 2390
Airflow (CMH) 277
Airflow (CFM) 164
Static - PR(mm-wc) 15
dBA 30
CAP. μf ---
ADMISSIBLE AMBIENT TEMP 55
Weight (KG) 4
